Large Torque Drilling Fluid Agitator / Fluid Mixing Equipment 1297 * 740 * 692mm

Xi'an TianRui Petroleum Machinery Equipment Co., Ltd.
Trust Seal
Verified Supplier
Credit Check
Supplier Assessment
Contact Now

Large Torque Drilling Fluid Agitator / Fluid Mixing Equipment 1297 * 740 * 692mm

  • 1
  • 2
  • 3

Brand Name : TR Solids Control

Model Number : TRJBQ11

Certification : API Certificate, ISO Certificate

Place of Origin : Xi'an,China

MOQ : 1 Set

Price : Negotiable

Payment Terms : T/T, L/C, D/A, D/P, Western Union

Supply Ability : 5000 Sets / Month

Delivery Time : 10 days after receiving deposit

Packaging Details : Wooden or iron pallet

Motor Power : 11kw

Impeller Speed : 60/72r/min

Impeller Diameter : 800mm

Impeller Qty : 2pcs

Ex Standard : ExdIIBt4/IECEX/A-TEX

Dimension : 1297*740*692mm

Weight : 430kg

Key Words : High quality Mud Agitator for well drilling fluid mixing system, with excellent performance and long service time

Contact Now

High Quality Drilling Fluid Solid Control Mud Agitators in Stock for Sale

Key Product Introduction

TRJBQ series mud Agitator, Less than 5.5 kW drilling mud Agitator adopts the blender cycloid speed reducer, and it is applied to the drug liquids mixing tank. This mud agitator has the advantage of compact structure, so it occupies small area. More than 7.5 kW Mud Agitator uses the turbo and worm gear speed reducer, with the large torque transmission, the revolution is steady, it works reliablely and has great merit. Common model of mud agitator is JBQ5.5kW, JBQ7.5kW, JBQ11kW and JBQ15kW.

TRJBQ series mud agitatoris are part of the drilling fluids solids control equipment, which is mainly used to agitate and mix the drilling mud to prevent solids particles from depositing in the circulating tank and to stabilize the performance of drilling fluids. It is composed of explosion-proof motor, speed reducer, motor base and blade. The motor and speed reducer, speed reducer and impeller shaft are connected by steel coupling. The impeller is welded with four blades.

Key Characterstics of Mud Agitator:

  1. Motor and gear box will be connected by coupling directly. Agitation speed is more stable.
  2. The gearbox use worm gear. More reliable.
  3. Optimized product structure, small size, compact structure.
  4. Power available ranging from 3 to 22KW.
  5. Good heat exchange performance makes agitator faster cool down.​
  6. Running smoothly, small operating noise, long usage life, less wearing parts, and cost-saving.

Technical Information of TRJBQ Series Drilling Agitator

Model Motor Power Impeller Speed Impeller Diameter Impeller Qty. Explosion-proof Standard Weight Dimension
TRJBQ3 3kw 60/72r/min 600mm 1

ExdIIBt4/IECEX/A-TEX

190kg 909×525×527mm
TRJBQ5.5 5.5kw 600mm 1 250kg 1072×610×588mm
TRJBQ7.5 7.5kw 650mm 2 380kg 1157×670×607mm
TRJBQ11 11kw 800mm 2 430kg 1297×740×692mm
TRJBQ15 15kw 950mm 2 480kg 1330×890×747mm
TRJBQ18.5 18.5kw 1000mm 2 740kg 1510×890×753mm
TRJBQ22 22kw 1100mm 2 780kg 1529×890×753mm
Remark Above weight and dimension exclude mud agitator shaft.

Large Torque Drilling Fluid Agitator / Fluid Mixing Equipment 1297 * 740 * 692mm

Our Service

TR Solids Control exported directly or sold with supporting drillers to more than 30 countries and regions in the world such as Russia, United States, Australia, Latin America and the Middle East etc. Making sure to support first-class solid-control equipment with developing“Made in China”as our own tasks, holding forward-looking to each task, every drawing has technicity to direct, every process has worker to follow up and every product has QC to check on. To provide customers with a full set of solid-control equipment solutions effectively is our company's goal.

Competitive Advantages


1. We offer high quality products at competitive price.
2. Shortest delivery time.
3. Flexible payment terms.
4. Timely after-sale service.
5. Most of our equipment can be replaceable with international brands.
6. Our products have been exported to Argentina, Egypt, US, Australia, Romania, Pakistan, Dubai, Abu Dhabi, Iran, India, Indonesia, Vietnam, Malaysia and many other countries.


Company Tenet
Customer's satisfaction is the highest pursuit of TR Solids Control.
